• A wide range of specialized spray guns: Application efficiency is exponentially improved • Multiple self-cleaning features eliminatematerial buildup: No gun clogging • Modular design: Fewer wearing parts、Easy disassembly and maintenanc • Special alloy material: Excellent wear and corrosion resistance and airtightness • Ergonomic design: Excellent comfort and reduced fatigue

GET A QUOTE

Description

Technical Parameter

Ratio of raw materials	1:1 -1:3
Max working pressure	15Mpa
Paper feed speed	1.6～2m/s
Whole Power	18KW
Table longitudinal travel	Customized length
Viscosity range of raw materials	200～1000CPS(under working temperature)
Heating temperature range	0℃~80℃
Cleaning method	Mechanical Self-Cleaning System
Electrical requirements	Three-phase 380V 50Hz/60Hz (customizable)
Working Flow	PLC-controlled and adjustable
Weight	584Kg
Tank capacity	A 80L, B 80L
Host size((L×W×H)	140011001570mm
Dimension((L×W×H)	40001100700mm

Standard Configuration

Mainframe	1set
Spray gun	1set
Transfer pump	built-in
Working platform	1set
Storage tank	2set
Random accessories	1set

Standard Configuration

Gross weight	700Kg
Package size (L×W×H)	1400mm1250mm1600mm

Frequently Asked Questions

What are the main components of a spray foam machine?

Proportioner: The main unit that houses the pumps, heaters, and controls. It precisely meters and heats the two liquid components (Iso and Resin).

What is the difference between a Plural-Component and a Single-Component machine?

This is the standard for professional SPF application. It has two separate material tanks, pumps, and hoses for the "A-side" (isocyanate) and "B-side" (resin/polyol blend). The machine meters, heats, and delivers them separately to the gun, where they are mixed.

What types of spray foam can I apply with these machines?

Softer, less dense, and vapor-permeable. Used primarily for interior wall insulation and sound dampening.

Why is material temperature so critical?

Temperature directly affects viscosity and reaction time. Properly heated material has a lower viscosity, which allows for better mixing at the gun tip, a more consistent spray pattern, and optimal foam rise and cure. Incorrect temperatures are a primary cause of application failures.
